| FILTER | PLPE SIZE |
FLOW RATES @7 bar g(100psig) |
DIMENSIONS(mm) | REPLACEMENT ELEMENTS | WEIGHT | ||||||
| scfm | Nm³/Min | A | B | C | D | E | Type | No. | Kg | ||
| G09 | G1/2 | 32 | 0.9 | 90 | 20 | 230 | 10 | 180 | EA09 | 1 | 1.4 |
| G19 | G3/4 | 67 | 1.9 | 90 | 20 | 230 | 10 | 180 | EA19 | 1 | 1.4 |
| G33 | G1 | 116 | 3.3 | 115 | 30 | 370 | 10 | 315 | EA33 | 1 | 2.8 |
| G40 | G1½ | 145 | 4.0 | 115 | 30 | 370 | 10 | 315 | EA40 | 1 | 2.8 |
| G60 | G1½ | 212 | 6.0 | 115 | 30 | 370 | 10 | 315 | EA60 | 1 | 2.8 |
| G70 | G2 | 250 | 7.0 | 155 | 40 | 535 | 10 | 350 | EA70 | 1 | 6.4 |
| G100 | G2 | 353 | 10 | 155 | 40 | 535 | 10 | 350 | EA100 | 1 | 6.6 |
| G140 | G2 | 494 | 14 | 155 | 40 | 535 | 10 | 350 | EA140 | 1 | 6.8 |
| G200 | G2½ | 706 | 20 | 175 | 50 | 710 | 24 | 420 | EA200 | 1 | 11.0 |
| G280 | G2½ | 988 | 28 | 175 | 50 | 925 | 24 | 550 | EA280 | 1 | 13.4 |
| G350 | G3 | 1235 | 35 | 217 | 60 | 780 | 24 | 420 | EA350 | 1 | 17.4 |
| F435 | 4"F | 1535 | 43.5 | 560 | 180 | 970 | 305 | 950 | EA145 | 3 | 85 |
| F580 | 5"F | 2048 | 58 | 560 | 205 | 1050 | 305 | 950 | EA145 | 4 | 100 |
| F615 | 5"F | 2172 | 61.5 | 625 | 205 | 1150 | 305 | 1050 | EA205 | 3 | 110 |
| F820 | 6"F | 2896 | 82 | 625 | 220 | 1205 | 305 | 1050 | EA205 | 4 | 120 |
| F855 | 6"F | 3019 | 85.5 | 560 | 220 | 1405 | 305 | 1300 | EA285 | 3 | 125 |
| F1140 | 6"F | 4026 | 114 | 560 | 220 | 1410 | 305 | 1300 | EA285 | 4 | 130 |
| F1425 | 8"F | 5032 | 142.5 | 600 | 220 | 1485 | 305 | 1050 | EA285 | 5 | 165 |
| F1995 | 8"F | 7045 | 199.5 | 650 | 260 | 1550 | 305 | 1300 | EA285 | 7 | 210 |
